Simrad EK80 Installation Manual

220
394149/C
Note
Thetechnicalspecicationsarethosevalidforthecomputerthatmaybeorderedfrom
KongsbergMaritimeasapartoftheEK80delivery.Forspecicationsrelatedtoalocally
purchasedcomputer,refertothedocumentationprovidedwiththeunit.
WideBandTransceiver(WBT)
•Type:WideBandTransceiver(WBT)
•Outlinedimensions
–Depth:213mm
–Width:438mm
–Height:84mm
•Weight:Approximately5kg
Ethernetswitch
•Manufacturer:BlackBox
•Manufacturer’swebsite:http://www.blackbox.co.uk
•Type:LBS209AE-R2
•Physicaldimensions:
–Height:44mm
–Width:22.8mm
–Depth:123mm
•Weight:1.2kg
Thesespecicationsweretakenfromthemanufacturer’swebsiteinJune2013.The
specicationsmaybealteredwithoutpriornotice.
Note
ThetechnicalspecicationsarethosevalidfortheEthernetswitchthatmaybeorderedfrom
KongsbergMaritimeasapartoftheEK80delivery.Forspecicationsrelatedtoalocally
purchasedEthernetswitch,refertothedocumentationprovidedwiththeunit.
Relatedtopics
385609ProcessorUnitoutlinedimensions,page206
388697WideBandTransceiver(WBT)outlinedimensions,page204
