394149/C

Mainsystemunits

Topics

Displaydescription,page18

ProcessorUnitdescription,page19

Ethernetswitch,page20

WideBandTransceiver(WBT)description,page20

Transducers,page21

Displaydescription

AdisplayisarequiredpartoftheEK80Widebandscienticechosounder.Forbest

readability,thedisplaymustbelocatedsothatitisbestprotectedfromglare,andwiththe

correctheightandangle.

AnycommercialdisplaycanbeusedwiththeEK80Widebandscienticechosounder,

providedthatthedisplaymeetstheminimumrequirements.

Note

ThedisplayisnotastandardpartoftheEK80delivery.Thisisacommercialitemthat

canbepurchasedlocally.

Thechosendisplaymustbedesignedformaritimeuse,anditmustmeettheminimum

performancespecications.Youmustalsomakesurethatthechosendisplaysupportsthe

videoformatsprovidedbytheProcessorUnit.

Tip

TheProcessorUnitofferstwovideooutputs.Twodisplaysmaythereforebeusedtoseethe

EK80presentations.Youmayplacethetwodisplaysnexttoeachother .Youmayalsochoose

toplacetheseconddisplayatanotherlocationonthevessel.

Thepresentationontheseconddisplayiscontrolledusingtheoperatingsystemfeatureson

theProcessorUnit.
