Simrad EK80 Installation Manual

394149/C
125
ground.Avoidgroundloops.Youmustusethesametypeofcableastheoriginaltransducer
cable,contactKongsbergMaritimeforadvice.
Westronglyrecommendthatyouinstallthetransducercableinasteelconduit.
Minimumcablerequirements
Notapplicable.Ifyouneedanextensioncable,contactyourdealer(orKongsbergMaritime)
forsupport.
SimradES38-7connectiontoacirculartransducersocket
TheES38-7transducershallbeconnectedtoterminalsAthroughNonacircular12-pin
Amphenoltransducersocket.ThissocketisusedontheGeneralPurposeTransceiver(GPT),
andonsomeversionsoftheWideBandTransceiver(WBT).
M
E
F
J
H
D
C
K
L
A
B
N
FOR WARD
4
3
2
1
12
3
4
1
2
H
L
D
A
E
B
F
C
J
M
N
(CD0808_003_006)
A
SectorCablecoloursTerminalon
socket
White
H
1
Black
J
Green
E
2
Black
F
Yellow
C
3
Black
D
Blue
A 4
Black
B
DigitaloutputRed
L
DigitalgroundBlack
M
ATransducerseenfromtop-
observethesectorlocations
relativetotheforwarddirection!
BSectors
CConnectorsonthe12-pin
Amphenoltransducersocket
DCircular12-pinAmphenol
transducersocketseenfrom
outside
Cablescreen
Screen
N
Cablelayoutandinterconnections
