Simrad EK80 - Simrad ES30-10 Connection to a Circular Transducer Socket

126
394149/C
ThecablescreenmustbeconnectedtothehousingonthetransducerplugandtoterminalN.
Note
Theblackwiresinthetransducercablearenotforgrounding.Youmustneverconnectthese
together,andyoumustnotconnectanyofthemtovesselground.
Ifyouneedtosplicethetransducercable,westronglyrecommendtheuseofametal
junctionboxwithpropercableglands.Thecablescreenmustbeconnectedtothecable
glands.Thecablescreenandthejunctionboxchassismustnotbeconnectedtovessel
ground.Avoidgroundloops.Youmustusethesametypeofcableastheoriginaltransducer
cable,contactKongsbergMaritimeforadvice.
Westronglyrecommendthatyouinstallthetransducercableinasteelconduit.
Minimumcablerequirements
Notapplicable.Ifyouneedanextensioncable,contactyourdealer(orKongsbergMaritime)
forsupport.
SimradES30-10connectiontoacirculartransducersocket
TheSimradES38-10splitbeamtransducershallbeconnectedtosocketsCthroughJ(and
N)onacircular12-pinAmphenoltransducersocket.ThissocketisusedontheGeneral
PurposeTransceiver(GPT),andonsomeversionsoftheWideBandTransceiver(WBT).
Theotherendofthecableispermanentlyxedtothetransducer.
M
E
F
J
H
D
C
K
L
A
B
N
FOR WARD
3
2
1
H
L
D
A
E
B
F
C
J
M
N
(CD0808_003_007)
A
1
2
3
SimradEK80
