ATransducers
BLicenseidentiîš¿cation
CConnectorsonthe12-pinAmphenoltransducersocket
DCircular12-pinAmphenoltransducersocketseenfromoutside
ThecablescreenmustbeconnectedtothehousingonthetransducerplugandtoterminalN.
Ifyouneedtosplicethetransducercable,westronglyrecommendtheuseofametal
junctionboxwithpropercableglands.Thecablescreenmustbeconnectedtothecable
glands.Thecablescreenandthejunctionboxchassismustnotbeconnectedtovessel
ground.Avoidgroundloops.Youmustusethesametypeofcableastheoriginaltransducer
cable,contactKongsbergMaritimeforadvice.
Westronglyrecommendthatyouinstallthetransducercableinasteelconduit.
Cableconnectionsversussoftwarelicenses
WhenmorethanonetransducershallbeconnectedtotheWideBandTransceiver(WBT),
yoursoftwarelicensemustsupportthis.Ifnecessary,additionallicensesmustbepurchased.
Ifyouhaveonlyonelicense,connectyourtransducertosocketsHandJonthe12-pin
Amphenolsocket.
Foradditionallicenses,connectasfollows:
License1License2License3License4
HJEF
C
D
A
B
Cablelayoutandinterconnections
