Installationdrawings
Thecustomer,ortheshipyardcontractedtodotheinstallation,mustproviderelevant
detailedvesselspecicmechanicaldrawings.
Note
Ifrequired,alldocumentsprovidedbytheshipyardforthephysicalinstallationoftheEK80
mustbeapprovedbythevessel’ snationalregistryandcorrespondingmaritimeauthority
and/orclassicationsociety.Suchapprovalmustbeobtainedbeforetheinstallationcan
begin.Theshipownerandshipyarddoingtheinstallationareresponsibleforobtainingand
payingforsuchapproval.
KongsbergMaritimeASmay,onspecialorder,provideassistancetothesedrawings.
Applicablegenericoutlinedimensionand/orproductionsdrawingsareprovidedinthe
Drawinglechapter.DrawingsmayalsobedownloadedinPDFand/orDWGformats
fromourwebsite.
•http://www.simrad.com/ek80
On-lineinformation
AllendusermanualsprovidedforoperationandinstallationofyourSimradEK80can
bedownloadedfromourwebsite.
•http://www.simrad.com/ek80
OurwebsitewillalsogiveyouinformationaboutotherSimradproducts.
Licenseinformation
TheEK80isalicensedproduct.Inordertoobtainalicense,contactyourlocaldealer.
Registeredtrademarks
Observetheregisteredtrademarksthatapply.
