Simrad EK80 Installation Manual

62
394149/C
cablestripperetc.Eachtoolmustbeprovidedinvarioussizes.Werecommendthatalltools
aredemagnetizedtoprotectyourequipment.
Context
ThepowersupplyprovidedwiththeWideBand
Transceiver(WBT)canbeinstalledinmanyways.
Somemountingkitsareavailable.
•Desktopmountingusingthebracketsprovided
withthepowersupply
•Wall/bulkheadmountingusingthewallbracket
mountingkit(optional)
Forspecialpurposes,ad-hocinstallationusingany
meansavailableisalsoapossibility.
Procedure
1Preparethelocationandthenecessarytools.
2Observetheinstallationrequirements.
aThepositionmustbechosentottheavailablecablelengthsbetweenthepower
supply,thetransceiverandtheACpoweroutlet.
bIfyouplacetheunitonthebridge,observethecompasssafedistance.
cMakesurethatenoughspaceismadeavailableformaintenancepurposes.
dMakesurethatadequateventilationisavailabletoavoidoverheating.
eEnsurethattheinstallationmethodallowsforthephysicalvibration,movements
andforcesnormallyexperiencedonavessel.
Note
Inordertoallowforfuturemaintenance,westronglyadvicethatyoumounttheunit
withitscablesandconnectorsavailableforimmediateaccess.
3Verifythatthechosenlocationmeetstherequirements.
4Ifyouinstallthepowersupplyusingthewall/bulkheadkit:
aMountthebracketinasuitablelocationusingsuitableboltsorscrews.
bPlacethepowersupplyintothebracketsothatthesmalllampisvisible.
