To Next Page

To Previous Page

394149/C

Tip

Tolearnmoreaboutthevariousvideostandards,exploretheseWikipediapages.

SVGAdescription

DVIdescription

HDMIdescription

DisplayPortdescription

(Photodownloadedfrom

www.tulembedded.com,

2015)

Theoutputsfromthegraphicadaptersarepositionedas

follows:

ADisplayPortoutput

BDisplayPortoutput

CHDMIoutput

DDVI-Ioutput

EDVI-Doutput

Note

ThetwoDVIoutputsarenotidentical.Ifyouwishtoconnect

astandardVGAdisplayusingaDVI-to-VGAadapter ,you

mustusetheleft

output(D).

1LocatethevideooutputsontherearsideoftheProcessor

Unit.

2Connectthedisplaycablefromtheappropriatesloton

therearsideoftheProcessorUnittothedisplay.

IfyouusetheDVIoutputandonlyonedisplay,usethe

leftsocket.

Relatedtopics

ProcessorUnitgraphicadapter,page100

MoxaCP114EL-ISeriallineadapter,page115

Cablelayoutandinterconnections
