132

394149/C

Note

Theblackwiresinthetransducercablearenotforgrounding.Youmustneverconnectthese

together,andyoumustnotconnectanyofthemtovesselground.

Ifyouneedtosplicethetransducercable,westronglyrecommendtheuseofametal

junctionboxwithpropercableglands.Thecablescreenmustbeconnectedtothecable

glands.Thecablescreenandthejunctionboxchassismustnotbeconnectedtovessel

ground.Avoidgroundloops.Youmustusethesametypeofcableastheoriginaltransducer

cable,contactKongsbergMaritimeforadvice.

Westronglyrecommendthatyouinstallthetransducercableinasteelconduit.

Minimumcablerequirements

Notapplicable.Ifyouneedanextensioncable,contactyourdealer(orKongsbergMaritime)

forsupport.
