Simrad EK80 Installation Manual

394149/C
177
8ClickOKtosavethechosenparametersandclosetheSelectInputsdialogbox.
9OntheI/OSetuppage,clickonceonthechosencommunicationporttoselectit.
10Denetherelevantcommunicationparameters.
aClickSetuptoopentheSerialPortSetupdialogbox.
bIntheSerialPortSetupdialogbox,denetherelevantparametersforthe
communication.
ThecommunicationparametersdenedforNMEA0183are:
•Baudrate:4800bitspersecond
•Databits:8
•Parity:None
•Stopbits:One
Someinstrumentsmayofferotherparametersand/orchoices.Youmustalways
checktherelevantdocumentationprovidedbythemanufacturer.
cClickOKtosavethechosenparametersandclosetheSerialPortSetupdialogbox.
11Verifythatthecommunicationportisfunctional.
aClickonacommunicationlinetoselectit.
bClickMonitortoopenthePortMonitordialogbox.
cVerifythatthedataowontheinputline(RxDatatexteld)isoperational.
Inordertomonitorthisdataow,theperipheralsystemmustbeactiveand
transmittinginformationtotheEK80.
dClickOKtoclosethePortMonitordialogbox.
Ifthedataowisnotpresent,wesuggestthefollowingactions:
•Checkthattheperipheralsystemhasbeenswitchedon.
•Checkthattheperipheralsystemisinfacttransmittinginformation.
•Checkthecables.
•Checkthatyouhavemadethephysicalconnectiontothecommunicationport
thatyouaremonitoring.
12ClickOKtosavethechosensettingsandclosethedialogbox.
Settingtowork
