Simrad EK80 Installation Manual

394149/C
29
designedformaritimeuse,anditmustmeettheminimumperformancespecications.
Youmustalsomakesurethatthechosendisplaysupportsthevideoformatsprovidedby
theProcessorUnit.
Wesuggestthatyoupurchasealargehigh-resolutiondisplay.
KongsbergMaritimemayprovideasuitabledisplay.Consultyourlocaldealeroragentfor
moreinformation.
Item
Ordernumber
Inthebox
Display335513
•DisplayHattelandJH19T14(19-inch,
1280x1024)
•Powercable
•Documentation
Mountinghardware339785
Ethernetswitch
IfyouusemorethanoneWideBandTransceiver(WBT),anEthernetswitchisrequired.
ThisisusedtoconnecteachWideBandTransceiver(WBT)totheProcessorUnit.The
EthernetswitchisnotapartoftheEK80scopeofsupply.
KongsbergMaritimemayprovideasuitableEthernetswitch.Consultyourlocaldealeror
agentformoreinformation.
Item
Ordernumber
Inthebox
Ethernetswitch352527
•EthernetswitchBlackBox
LBS209AE-R2
•Powersupply
•Documentation
Relatedtopics
ProcessorUnitdescription,page19
Ethernetswitch,page20
Splitbeamtransducers,page23
Widebandtransducers,page24
Depthratedtransducers,page25
385609ProcessorUnitoutlinedimensions,page206
Minimumtechnicalrequirementsfordisplay,page225
Minimumcomputerrequirements,page224
