Simrad EK80 Installation Manual

58
394149/C
•ThepositionmustbechosentottheavailablecablelengthsbetweentheWide
BandTransceiver(WBT)andtheotherunitsitconnectsto.Shortdistancetothe
transducersisalwaysrstpriority.
•IfyouplacingtheWideBandTransceiver(WBT)onthebridge,observethe
compasssafedistance.
•Makesurethatenoughspaceismadeavailableformaintenancepurposes.
•Makesurethatadequateventilationisavailabletoavoidoverheating.
•Ensurethattheinstallationmethodallowsforthephysicalvibration,movements
andforcesnormallyexperiencedonavessel.
Note
Inordertoallowforfuturemaintenance,westronglyadvicethatyoumounttheunit
withitscablesandconnectorsavailableforimmediateaccess.
3Verifythatthechosenlocationmeetstherequirements.
4PlacetheWideBandTransceiver(WBT)intheselectedposition.
5Securetheunitusing6.5mmboltsthroughthetwomountingbrackets.
6Connectthecables.
Note
Whenyouconnectthecables,makesurethattheyareallproperlysecured,andable
towithstandthevibrationandmovementsofthevessel.
Relatedtopics
388697WideBandTransceiver(WBT)outlinedimensions,page204
Equipmenthandling,page227
Compasssafedistance,page223
