394149/C

Procedure

1LocatetheEthernetconnectorsontherearsideoftheProcessorUnit.

Useoneofthesocketsidentiedwiththearrows.

Note

DonotuseanyoftheEthernetsocketsontheProcessorUnit’ sdefaultconnectorpanel.

2LocatetheEthernetconnector(identiedwiththearrow)ontheWideBandTransceiver

(WBT).

3VerifythatthenecessarylengthoftheEthernetcabledoesnotexceedthemaximum

operationallength.

4ConnecttheEthernetcablefromtheProcessorUnittotheEthernetsocketontheWide

BandTransceiver(WBT).

IfyourEK80usesmorethanoneWideBandTransceiver(WBT),connectthecable

toahighcapacityEthernetswitch.Fromthisswitch,connectseparatehighquality

Ethernetcablestoeachtransceiver.

Relatedtopics

RJ45HighspeedEthernetcable(1000Base-t),page117

Cablelayoutandinterconnections
