Sirona Intego - Page 218

64 57 498 D3543
218 D3543.201.01.05.02 08.2016
5Care, cleaning and maintenance by the practice team Sirona Dental Systems GmbH
5.3Instruments and instrument hoses Operating Instructions INTEGO
✔ The Purge dialog is displayed on the touchscreen.
1. Use the – and + keys to set the purging time.
2. Touch the
Start key.
Purging water lines
✔ The Purge function activated display is shown on the touchscreen.
1. Remove the instruments to be purged from the holder and hold them
over the cuspidor or over a watertight container with sufficient
capacity. With the CS dentist element: Move the swivel arm of the
instruments to be purged into the operating position so that the weight
of the instrument hoses allows them to remain in this position.
 After an instrument is removed, the purge process starts
automatically after about 5 seconds (except for the 3-way
syringe). The removed instruments are purged with water for the
duration of the set purging time.
2. Place the removed instruments back in their holders after the purging
process.
3. Hold the 3-way syringe of the dentist and assistant element over the
cuspidor or over a watertight container with sufficient capacity and
press the water key for at least 20 seconds.
4. Touch the
Stop key to end the purge program.
 After all instruments have been put back in their holders, the
Purge function activated display disappears. The Start dialog is
shown.
120 s
Start
Start
Stop
max.
CAUTION
Do not purge more than two burs simultaneously.
If the treatment center features the option of a third burr drive, the water
flow rate is reduced when purging simultaneously.
➢ Do not remove more than two burr drives for purging. Purge the third
burr drive separately afterwards.
Stop
