10.5
Other dialogs
10.5.1 Timer screen
Time loop
If the key is highlighted orange, the countdown will automatically be
restarted when the set time has expired.
Acoustic signal
If the key is highlighted orange, an acoustic signal will sound when the set
time has expired.
10.5.2 Tumbler filling setting dialog
Coupling tumbler filling to mouth rinsing position
If the key is highlighted orange, the tumbler filling function will
automatically be switched on for the duration of the preset filling time
when the mouth rinsing position chair program (S) is activated.
Setting filling time
10.5.3 Flushing settings screen
Linking flushing to mouth rinsing position S
Following movement to mouth rinsing position S, the flushing function
automatically switches on for the duration of the set flushing time.
10.5.4 Highspeed handpiece light setting dialog
Instrument setup
Calls up the
Highspeed handpiece instrument setup
Limitation type
To select the limitation of voltage or current of the highspeed handpiece
light or to switch off the power supply.
Setting the limitation
Setting of the voltage or current limitation
S
2
1
0S
S
---
mA
V
3.20 V
