Ski-Doo REV Series Shop Manual

Section04ENGINE
Subsection 01 (593, 593 HO, 593 HO SDI AND 793 HO ENGINE TYPES)
A33C2DA
Unplug spark plug cables.
Detach upper thermostat hose from thermostat
housing.
A33C2EA
1
1. Remove this hose
Disconnect temperature sensor connectors.
A33C2FA
Remove spark plugs and install spark plug lift ring
(P/N 529 035 830) at the farthest spark plug hole.
1
A33C18A
1. Spark plug lift ring
Remove RAVE valves.
Unscrew engine support bolts no. 1.
A33C2GA
1
LEFT SIDE OF VEHICLE
1. Engine support bolts
mmr2004-Rev 83
