Ski-Doo REV Series Shop Manual

Section04ENGINE
Subsection 01 (593, 593 HO, 593 HO SDI AND 793 HO ENGINE TYPES)
In case of a play, turn blade upside down and
recheck. If there is still a play, replace blade and/or
valve body.
Check distance from blade stopper outer edge and
distance from center of reed valve block.
A06C36A
A A
TYPICAL
A. 18.7 - 0, + 0.75 mm (.736 - 0, + .030 in)
Bent blade stopper as required to obtain the
proper distance.
Blade stoppers may slightly interfere with cylinder
during installation. Adjusted distance will be re-
duced automatically upon installation.
mmr2004-Rev 99

Ski-Doo REV Series Specifications

General

Chassis	REV
Track Width	15 in
Fuel Capacity	10.6 gal
Seating Capacity	1
Reverse	Available on most models
Electric Start	Available on most models
