Section11TECHNICALDATA
Subsection 02 (ENGINES)
GSX Limited
GSX 600 HO SDI Limited and GSX 800 HO Limited
600 HO SDI 800 HO
Country CAN/U.S. CAN/U.S.
Engine Type 593 SDI 793 HO
FUEL SYSTEM
Carburetor/throttle body type PTO/MAG Dell’Orto without IACV TM40–B292
Main jet PTO/MAG — 400
Needle jet PTO/MAG — P-0
Pilot jet PTO/MAG — 17.5
Needle identification PTO/MAG — 9DGI7–58
Clip position PTO/MAG —
Slide cut-away — 2.0
Float adjustment mm (in) — —
Air or pilot screw adjustment ± 1/16 turn — 1.5
Idle speed ± 200 RPM 1500
Gas type Super unleaded
Pump octane number 91 (R+M)/2 or higher
Gas/oil ratio Injection
COOLING SYSTEM
Type Liquid
Deflection mm (in) —
Axial fan belt adjustment
Force kg (lbf) —
Thermostat opening temperature °C (°F) 42 (108)
Radiator cap opening pressure kPa (PSI) 90 (13)
TIGHTENING TORQUE (engine cold)
Drive pulley retaining screw
(7)
Exhaust manifold nuts or bolts 22 N•m (16 lbf•ft)
Magneto ring nut 125 N•m (92 lbf•ft)
M6 9N•m(80lbf•in)
Crankcase nuts or screws
M8 29 N•m (21 lbf•ft)
Crankcase/engine support nuts or screws 35 N•m (26 lbf•ft)
Cylinder head screws 29 N•m (21 lbf•ft)
Crankcase/cylinder nuts or screws 40 N•m (30 lbf•ft)
Axial fan shaft nut —
