Ski-Doo REV Series Shop Manual

Section 11 TECHNICAL DATA
Subsection 02 (ENGINES)
MXZ
MXZ 500 SS Adrenaline and MXZ 500 SS Trail
500 SS Adrenaline 500 SS Trail 500 SS Trail
Country CAN/U.S. CAN/U.S. EUROPE
Engine Type 593
ENGINE
Number of cylinder 2
Bore Standard mm (in) 76 (2.992)
Stroke mm (in) 65.80 (2.591)
Displacement cm
3
(in
3
) 597.00 (36.431)
Compression ratio 12.0 ± 0.5
Maximum power engine speed
(1)
8000 ± 100 RPM
1
st
Semi-trapezoidal
Piston ring type
2
nd
—
New mm (in) 0.40 to 0.55 (.016 to .022)
Ring end gap
Wear limit mm (in) 1.0 (.039)
New mm (in) 0.04 to 0.09 (.0016 to .0035)
Ring/piston groove clearance
Wear limit mm (in) 0.2 (.0079)
New mm (in) 0.120 ± 0.016 (.0047 ± .0006)
Piston/cylinder wall clearance
Wear limit mm (in) 0.2 (.0079)
Maximum crankshaft end play
(2)
New mm (in) 0.3 (.012)
Maximum crankshaft deflection at PTO Wear limit mm (in) 0.06 (.0024)
New mm (in) 0.390 to 0.737 (.0154 to .0290)
Connecting rod big end axial play
Wear limit mm (in) 1.2 (.0472)
ELECTRICAL
Magneto generator output W 360
Ignition type CDI
Make and type NGK BR9ECS
(8)
Spark plug
Gap mm (in) 0.40 to 0.50 (.016 to .020)
Ignition timing BTDC
(3)
mm (in) 2.49 (.098)
Trigger coil
(4)
190 to 300
Low speed —
Generating coil
(4)
High speed —
Lighting coil
(4)
0.1 to 1.0
Primary —
High tension coil
(4)
Secondary —
mmr2004-Rev 355
