161
Bottom Push-to-Twist Joint
9. The bottom push-to-twist joint
should be smooth to operate.
If it is not, then strip and
check the joint.
10. Loosen the two small set
screws until they are fl ush
with the outer body. Remove
the stainless steel arm from
the cast body.
11. Check the condition of the
groove and notches. Ensure that
there are no rough edges and no
foreign bodies.
12. Check inside the machined
body. Make sure that there are
no grooves cut into the body by
either the stainless steel arm or
foreign bodies. If there are any
signs of wear, replace the parts.
13. Remove the plastic washer
and spring. Check the two
“O” rings remaining in the
machined body for damage.
If you do not see any
damage, re-grease the parts
with oxygen-safe grease
and reassemble. Take care
to insert the two small set
screws into the groove on the
stainless steel arm. Do not
over-tighten the two screws to
the point where they stop the
arm from twisting.
Detailed Repair Procedures
