162
Top Swivel
1. Check that the top swivel
is free to rotate and also
check the bag port tapper
for damage.
2. Remove the small set screw
and remove the machined
body from the arm.
3. Check for any damage
inside the body and that
the two “O” rings are not
damaged. Replace any
damaged parts.
4. If you do not see any
damage, re-grease with
oxygen safe grease and
reassemble Ensure that the
set screw is located in the
groove.
Refi tting and testing
Refi t the arm to the absorber, making
sure that the two screws (SM0650 M6 x
30 and SM0692 washers) are secure.
