Navigate to Management > Disciplining, and click the GEAR icon in the top-right corner
of the Status panel.
14.
Set the value Maximum TFOM for Sync to4 (this will make NetClock to go out of sync if
the phase error is greater than 1μs).
15.
Set the value for Holdover Timeout to 10s, to allow NetClock to exit holdover quickly.
16.
Leave the Phase Error Limit at 0, and do not check any of the checkboxes (or, for more
information, see "Configuring the Oscillator" on page215).
2.15.12.4 Configuring NTP over Anycast (BGP)
To configure NTP over Anycast, using BGP (Border Gateway Protocol):
1.
Confirm that your existing network infrastructure is Anycast capable, and uses BGP.
Determine the network specifics, such as your Autonomous System (AS) number, Neigh
bor’s address and Neighbor’s AS number.
2.
In the NetClock Web UI, navigate to MANAGEMENT > Network > NTP Setup.
3.
In the Actions Panel, click NTP over Anycast.
4.
In the NTP Anycast window, select the General tab.
5.
On the General tab, select your desired IP Version. This selection automatically com
municates with the BGP tab and displays the neighbor address field based on your
needs.
6.
Select the port to associate the Anycast service with (depending on the option card con
figuration of your unit, there may be only ETH0 available). If you desire IPv6 func
tionality, you must also select the IPv6 port address since there may be multiple IPv6
addresses on a single port.
7.
In the NTP Anycast window, navigate to the BGP tab.
8.
On the BGP tab, check Enable.
9.
Input your AS number.
10.
Input the neighbor's address.
11.
Input the neighbor's AS number.
12.
Click Submit.
13.
Select the port address to associate the Anycast service with (because there may be mul
tiple addresses on a single port), and click Submit. If no addresses appear, an IP
address must be added to the port (see "Network Ports" on page59).
14.
Next, specify the maximum TFOM Setting (Time Figure of Merit), and the Holdover
Timeout value. These two parameters determine NetClock's accuracy "tolerance win
dow": A small window will cause NetClock to deliver a more accurate time window, but
also will cause it to quickly withdraw from the Anycast server pool, i.e. declare itself an
invalid reference. (For more information about TFOM, see "Configuring the Oscillator"
