Available static IP
Address
This is the unique address assigned to the NetC
lock unit by the network administrator. The default
static IP address of the NetClock unit is
10.10.201.1.
Subnet mask (for the net
work)
The subnet mask defines the number of bits taken
from the IP address that are used in the network
portion. The number of network bits used in the net
mask can range from 8 to 30 bits.
Gateway address
The gateway (default router) address is needed if
communication to the NetClock is made outside of
the local network. By default, the gateway is dis
abled.
Table 2-3:
Required Network information
If your network does not support DHCP, use the front panel LCD and keypad (see "Front Panel
Keypad, and Display" on page6) to input the desired static IP, subnet mask, and gateway
address.
Network Bits Equivalent Netmask Network Bits Equivalent Netmask
30 255.255.255.252 18 255.255.192.0
29 255.255.255.248 17 255.255.128.0
28 255.255.255.240 16 255.255.0.0
27 255.255.255.224 15 255.254.0.0
26 255.255.255.192 14 255.252.0.0
25 255.255.255.128 13 255.248.0.0
24 255.255.255.0 12 255.240.0.0
23 255.255.254.0 11 255.224.0.0
22 255.255.252.0 10 255.192.0.0
21 255.255.248.0 9 255.128.0.0
20 255.255.240.0 8 255.0.0.0
19 255.255.224.0
Table 2-4:
Subnet mask values
2.14 Configuring Network Settings
Before configuring the network settings, you need to setup access to NetClock web user inter
face ("Web UI"). This can be done by assigning a static IP address, or using a DHCP address.
For more information, see "Setting up an IP Address" on page42.
56
CHAPTER 2 • NetClock User Reference Guide Rev. 16
2.14 Configuring Network Settings
