Pin Layout
Table 5-6:
ASCII RS-485 pin assignment
Pin Signal Function
1 RS-485 TX+ ASCII Output 1
2 RS-485 TX-
3 GND
4 RS-485 TX+ ASCII Output 2
5 RS-485 TX-
6 GND
7 RS-485 RX+ ASCIIInput
8 RS-485 RX-
9 GND
10 n/a Not used
5.2.3 Accessing Option Module Settings via the WebUI
The topics below describe WebUI functionality that is common to all Option Modules.
