2.16 Configuring Input References
Depending on the type of input reference, some of its settings may be user-editable. To access
these settings for a given input reference, choose one of the two methods described below.
Note: The illustrations shown below are examples. The windows displayed in
your Web UI may look differently.
There are two ways to access the settings Status window for an input reference:
Configuring input reference settings, method 1:
1.
Under INTERFACES > REFERENCES, click the desired reference.
2.
The Status window for the specific reference you selected will be displayed. Click the Edit but
ton in the bottom-left corner.
3.
The settings window for the chosen reference will be displayed. Edit the field(s) as desired.
Configuring input reference settings, method 2:
1.
In the INTERFACES > REFERENCES drop-down menu, click REFERENCES (white on orange), or
an input reference category ("GNSS reference", for example).
2.
In the Status window, click the GEAR button next to the desired input reference.
3.
The settings window for the chosen reference will be displayed. Edit the field(s) as desired.
2.17 Configuring Outputs
Depending on the type of output interface, some of its settings may be user-editable. To access
these settings for a given output, choose one of the two methods described below.
Note: The illustrations shown below are examples. The windows displayed in
your Web UI may look differently.
Editing output settings, method 1:
1.
Under INTERFACES: OUTPUTS, click the desired output.
2.
The Status window for the specific reference you selected will be displayed. Click the
Edit button in the bottom-left corner.
2.16 Configuring Input References
CHAPTER 2 • NetClock User Reference Guide Rev. 16
137
