HH Hours (00-23)
: Colon separator
MM Minutes (00-59)
SS Seconds (00-60)
The leading edge of the first character (CR) marks the on-time point of the data stream.
The time synchronization status character (I) is defined as described below:
? When the receiver is unable to track any satellites and the time synchronization lamp is red.
* When the receiver time is derived from the battery backed clock or set manually through the Setup Port
Interface.
E x a m p l e :
FRI 20APR01 12:45:36
The example data stream provides the following information:
Sync
Status
The clock is not time synchronized to GNSS. Time is derived from the battery backed clock or
set manually
Date Friday, April 23, 2015
Time 12:45:36
5.4.6 Spectracom Format 1S
Format 1S (Space) is very similar to Format 1, with the exception of a space being the first char
acter of Days 1 through 9 of each month (instead of the leading “0” which is present in Format
1).
Most external systems utilizing Data Format 1 will look for a single digit day of the month for
day 1 through day 9, with a space in front of each digit (^1, ^2, ^3 … 10, 11…) whereas
other systems need to see a two digit day of the month for all days 1 through 9 with a leading
0 instead of a space (01, 02, 03… 10, 11…).
If your device requires the single digit day of the month for days 1 through 9 (i.e. 1, 2,
etc.), select Format 1S.
If your device requires the two digit day of the month for days 1 through 9 (i.e. 01, 02,
etc.), select Format 1 instead. Refer to "Spectracom Format 1" on the previous page for
information on Format 1.
392 NetClock User Reference Guide
