Type Connector
(1) Ethernet 10/100Base-T RJ-45 (auto-sensing)
(1) RS-232 Serial Connector DB9 female
(1) RS-485 Once-per-Second 3.81 mm Terminal Block
(1) IRIG B/E, IEEE 1344/C37.118-2005 (AM/TTL) output BNC
(1) 1 Pulse Per Second (1PPS) output BNC
(1) 10 MHz Frequency output BNC
(2) Relay / Alarm Outputs 3.81 mm Terminal Block
1.5.2 NetClock 9483: Optional Outputs
Several Option Modules are available for NetClock 9483, providing additional outputs and
functionality:
Type Connector
(3) 10/100/1000Base-T [Multi-Ethernet] RJ-45 (auto-sensing)
(1) 1.544 or 2.048 MHz
(2) 1.544 or 2.048 MHz
[T1/E1 Balanced]
3.81 mm Terminal Block
(1) PTP (IEEE 1588) RJ-45
For more information, see "NetClock 9483 Option Modules" on page335.
1.5.3 NetClock 9489 Standard Inputs and Outputs
I/O Type Connector
I/O (1) Ethernet 10/100Base-T RJ-45 (auto-sensing)
Output (1) 1 Pulse Per Second (1PPS) BNC
Outputs (2) RS-485 Once-per-Second 3.81 mm Terminal Block
Input (1) RS-485 Once-per-Second 3.81 mm Terminal Block
For more information, see "NetClock 9489 In-/Outputs" on page336.
1.5 Inputs & Outputs
CHAPTER 1 • NetClock User Reference Guide Rev. 16
5
