purchase, and information regarding configuration and usage that can be used after install
ation.
Also covered are commonly used Web UI procedures for the configuration of option modules,
and the status review of option module inputs and outputs.
Table 5-5:
Option Modules available for NetClock 9483
Option
Name
Module/PN Description Refer to Section
NENA 1209-1F NENA-Compliant Module
"NENA-Compliant Module" on
page348
Option 16 1209-06 Gigabit Ethernet (3X,
10/100/1000BaseT)
"Gigabit Ethernet Module [Option 16]"
on page359
Option 13 1209-0A T1/E1 – (100/20 Ω)
"T1/E1 Out Module [Option 13]" on
page361
Contact sales@spectracom.com general inquiries regarding option module card functionality
or availability.
If you do not have a NetClock 9483 product that already shipped pre-configured with specific
option modules, or if you have purchased new option modules for your NetClock 9483, refer
to the Option Card Installation Guide for NetClock 9400 Series document for detailed
installation steps.
5.2.2 NetClock 9489 In-/Outputs
Figure 5-1: Rear panel NetClock Model 9489
5.2.2.1 1PPS Output
The NetClock 9489 1PPSOutput is identical to the NetClock 9483. See "1PPS Output" on
page22.
