The Primary Navigation Bar provides access to all menus:
HOME: Return to the HOME screen (see above)
INTERFACES: Access the configuration pages for …
… references (e.g., GNSS, NTP)
… outputs (e.g. 10 MHz, PPS, NTP) and
… installed input/output option cards.
MANAGEMENT: Access the NETWORK setup screens, and OTHER setup screens e.g., to
configure Reference Priorities, System Time, and the Oscillator.
TOOLS: Opens a drop-down menu for access to the system maintenance screens and sys
tem logs.
HELP: Provides Spectracom Service Contact Information and high-level system con
figurations you may be required to furnish when contacting Spectracom Service.
1.9.2 The INTERFACES Menu
The INTERFACES menu on the Main screen provides access to NetClock's:
External REFERENCES e.g., the GNSS reference input
Detected OUTPUTS, such as 10 MHz and 1PPS
Installed OPTIONS.
16
CHAPTER 1 • NetClock User Reference Guide Rev. 16
