PTP
Time
Scale
Arbitrary
Time
Scale
Clock Class Definition
187 193 Time and 1pps references are in holdover state, not within specifications, and PTP clock
may be a slave to another clock in the domain.
255 255 Class assigned to “Slave-Only” clocks.
248 248 “Unknown” class.
Ethernet Status
Current IP Address: The IP address currently being used by the PTP interface.
Note: If the PTP Module is set up for DHCP but fails to obtain an IP address, it will
use the Static IP instead. To reacquire a DHCP address, reset the module via the
Main tab in the PTP settings window.
Current Network Mask: The Network Mask currently being used by the PTP interface.
Current Gateway: The Gateway address currently being used by the PTP interface.
Port Status
Port State: Reports the current state of the PTP State Machine:
Disabled: PTP Ethernet port is Disabled. See PTP Setup/Network page, PTP Net
work Settings options.
Initializing: Ethernet link is unplugged/PTP Module is in power-up state. A Master
Clock doesn’t leave this state while it can’t get the current time and syn
chronization references from NetClock to synchronize with it.
Listening: PTP module is looking for a Master Clock.
Master: PTP Master has become the active Master Clock on the network.
Passive: PTP Module has become a Passive Master Clock. (There is another
Master Clock on the network with better quality or higher priority). This Master
will wait until the Best Master Clock Algorithm determines it should become the
best Master Clock, and then it will transition to the Master Clock state.
Uncalibrated: PTP Slave has selected a Master Clock on the network attempts to
synchronize with it using sync packets.
One Step Mode: Determines the number of steps in the PTP protocol. Will be one
of the following:
374 NetClock User Reference Guide
