HH Hours (00-23)
: Colon separator
MM Minutes (00-59)
SS Seconds (00- 60)
D Daylight Saving Time indicator (S,I,D,O)
TZ Time Zone
XX Time Zone offset (00-23)
The leading edge of the first character (CR) marks the on-time point of the data stream.
The time synchronization status character (I) is defined as described below:
? When the receiver is unable to track any satellites and the time synchronization lamp is red.
* When the receiver time is derived from the battery backed clock or set manually through the Setup Port
Interface.
The Daylight Saving Time indicator (D) is defined as:
S During periods of Standard time for the selected DST schedule.
I During the 24-hour period preceding the change into DST.
D During periods of Daylight Saving Time for the selected DST schedule.
O During the 24-hour period preceding the change out of DST.
E x a m p l e :
271 12:45:36 DTZ=08
The example data stream provides the following information:
390 NetClock User Reference Guide
APPENDIX
