Flexible static memory controller (FSMC) RM0090

1546/1731 DocID018909 Rev 11

Figure 439. Mode2 write accesses

Figure 440. Mode B write accesses

The differences with mode1 are the toggling of NWE and the independent read and write

timings when extended mode is set (Mode B).

A[25:0]

NOE

ADDSET (DATAST + 1)

Memory transaction

NEx

D[15:0]

HCLK cycles HCLK cycles

NWE

NADV

data driven by FSMC

ai15562

1HCLK

A[25:0]

NOE

ADDSET (DATAST + 1)

Memory transaction

NEx

D[15:0]

HCLK cycles HCLK cycles

NWE

NADV

data driven by FSMC

ai15563

1HCLK
