DocID018909 Rev 11 707/1731

RM0090 Window watchdog (WWDG)

710

As an example, let us assume APB1 frequency is equal to 24 MHz, WDGTB[1:0] is set to 3

and T[5:0] is set to 63:

Refer to the table below for the minimum and maximum values of the t

WWDG

22.5 Debug mode

When the microcontroller enters debug mode (Cortex

-M4 with FPU core halted), the

WWDG counter either continues to work normally or stops, depending on

DBG_WWDG_STOP configuration bit in DBG module. For more details, refer to

Section 38.16.2: Debug support for timers, watchdog, bxCAN and I2C.

Table 108. Minimum and maximum timeout values at 30 MHz (f

PCLK1

)

Prescaler WDGTB

Min timeout (µs)

T[5:0] = 0x00

Max timeout (ms)

T[5:0] = 0x3F

1 0 136.53 8.74

2 1 273.07 17.48

4 2 546.13 34.95

8 3 1092.27 69.91

WWDG

1 24000⁄ 4096× 2

× 63 1+()× 21,85ms==
