Analog-to-digital converter (ADC) RM0090
432/1731 DocID018909 Rev 11
13.13.17 ADC common regular data register for dual and triple modes
(ADC_CDR)
Address offset: 0x08 (this offset address is relative to ADC1 base address + 0x300)
Reset value: 0x0000 0000
13.13.18 ADC register map
The following table summarizes the ADC registers.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
DATA2[15:0]
rrrrrr r r r r rrrrrr
1514131211109876543210
DATA1[15:0]
rrrrrr r r r r rrrrrr
Bits 31:16 DATA2[15:0]: 2nd data item of a pair of regular conversions
– In dual mode, these bits contain the regular data of ADC2. Refer to Dual ADC mode.
– In triple mode, these bits contain alternatively the regular data of ADC2, ADC1 and ADC3.
Refer to Triple ADC mode.
Bits 15:0 DATA1[15:0]: 1st data item of a pair of regular conversions
– In dual mode, these bits contain the regular data of ADC1. Refer to Dual ADC mode
– In triple mode, these bits contain alternatively the regular data of ADC1, ADC3 and ADC2.
Refer to Triple ADC mode.
Table 71. ADC global register map
Offset Register
0x000 - 0x04C ADC1
0x050 - 0x0FC
Reserved
0x100 - 0x14C ADC2
0x118 - 0x1FC
Reserved
0x200 - 0x24C ADC3
0x250 - 0x2FC
Reserved
0x300 - 0x308 Common registers
Table 72. ADC register map and reset values for each ADC
Offset Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12
11
10
9 8 7 6 5 4 3 2 1 0
0x00
ADC_SR
Reserved
OVR
STRT
JSTRT
JEOC
EOC
AWD
Reset value 000000
