RM0090 General-purpose timers (TIM2 to TIM5)
640
18.4.21 TIMx register map
TIMx registers are mapped as described in the table below:
Table 99. TIM2 to TIM5 register map and reset values
Offset Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12
11
10
9 8 7 6 5 4 3 2 1 0
0x00
TIMx_CR1
Reserved
CKD
[1:0]
ARPE
CMS
[1:0]
DIR
OPM
URS
UDIS
CEN
Reset value 0000000000
0x04
TIMx_CR2
Reserved
TI1S
MMS[2:0]
CCDS
Reserved
Reset value 00000
0x08
TIMx_SMCR
Reserved
ETP
ECE
ETPS
[1:0]
ETF[3:0]
MSM
TS[2:0]
Reserved
SMS[2:0]
Reset value 000000000000 000
0x0C
TIMx_DIER
Reserved
TDE
COMDE
CC4DE CC3DE CC2DE CC1DE
UDE
Reserved
TIE
Reserved
CC4IE CC3IE CC2IE CC1IE
UIE
Reset value 0000000 0 00000
0x10
TIMx_SR
Reserved
CC4OF CC3OF CC2OF CC1OF
Reserved
TIF
Reserved
CC4IF CC3IF CC2IF CC1IF
UIF
Reset value 0000 0 00000
0x14
TIMx_EGR
Reserved
TG
Reserved
CC4G CC3G CC2G CC1G
UG
Reset value 000000
0x18
TIMx_CCMR1
Output Compare
mode
Reserved
OC2CE
OC2M
[2:0]
OC2PE
OC2FE
CC2S
[1:0]
OC1CE
OC1M
[2:0]
OC1PE
OC1FE
CC1S
[1:0]
Reset value 0000000000000000
TIMx_CCMR1
Input Capture
mode
Reserved
IC2F[3:0]
IC2
PSC
[1:0]
CC2S
[1:0]
IC1F[3:0]
IC1
PSC
[1:0]
CC1S
[1:0]
Reset value 0000000000000000
0x1C
TIMx_CCMR2
Output Compare
mode
Reserved
O24CE
OC4M
[2:0]
OC4PE
OC4FE
CC4S
[1:0]
OC3CE
OC3M
[2:0]
OC3PE
OC3FE
CC3S
[1:0]
Reset value 0000000000000000
TIMx_CCMR2
Input Capture
mode
Reserved
IC4F[3:0]
IC4
PSC
[1:0]
CC4S
[1:0]
IC3F[3:0]
IC3
PSC
[1:0]
CC3S
[1:0]
Reset value 0
000000000000000
0x20
TIMx_CCER
Reserved
CC4NP
Reserved
CC4P CC4E
CC3NP
Reserved
CC3P CC3E
CC2NP
Reserved
CC2P CC2E
CC1NP
Reserved
CC1P CC1E
Reset value 0 0 0 0 0 0 0 0 0 0 0 0
0x24
TIMx_CNT
CNT[31:16]
(TIM2 and TIM5 only, reserved on the other timers)
CNT[15:0]
Reset value 000000000000000000 0 0 000000000000
0x28
TIMx_PSC
Reserved
PSC[15:0]
Reset value 0000000000000000
