Flexible static memory controller (FSMC) RM0090

1586/1731 DocID018909 Rev 11

Bits 31:0 ECCx[31:0]: ECC result

This field provides the value computed by the ECC computation logic. Table 247 hereafter

describes the contents of these bit fields.

Table 247. ECC result relevant bits

ECCPS[2:0] Page size in bytes ECC bits

000 256 ECC[21:0]

001 512 ECC[23:0]

010 1024 ECC[25:0]

011 2048 ECC[27:0]

100 4096 ECC[29:0]

101 8192 ECC[31:0]
