12.3.7 EXTI register map
Table 64 gives the EXTI register map and the reset values.
Refer to Section: Memory map for the register boundary addresses.
Table 63. External interrupt/event controller register map and reset values
Offset Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12
11
10
9 8 7 6 5 4 3 2 1 0
0x00
EXTI_IMR
Reserved
MR[22:0]
Reset value 00000000000000000000000
0x04
EXTI_EMR
Reserved
MR[22:0]
Reset value 00000000000000000000000
0x08
EXTI_RTSR
Reserved
TR[22:0]
Reset value 00000000000000000000000
0x0C
EXTI_FTSR
Reserved
TR[22:0]
Reset value 00000000000000000000000
0x10
EXTI_SWIER
Reserved
SWIER[22:0]
Reset value 00000000000000000000000
0x14
EXTI_PR
Reserved
PR[22:0]
Reset value 00000000000000000000000
