DocID018909 Rev 11 523/1731

RM0090 Advanced-control timers (TIM1&TIM8)

581

Figure 101. Counter timing diagram, internal clock divided by 2

Figure 102. Counter timing diagram, internal clock divided by 4, TIMx_ARR=0x36

1. Center-aligned mode 2 or 3 is used with an UIF on overflow.

Figure 103. Counter timing diagram, internal clock divided by N

CK_PSC

0002 0000 0001 0002 0003

CNT_EN

Timer clock = CK_CNT

Counter register

Update interrupt flag (UIF)

0003

0001

Counter underflow

Update event (UEV)

CK_PSC

0036 0035

CNT_EN

Timer clock = CK_CNT

Counter register

Update interrupt flag (UIF)

0034

0035

Counter overflow

Update event (UEV)

Timer clock = CK_CNT

Counter register

Update interrupt flag (UIF)

Counter underflow

Update event (UEV)
