LCD-TFT Controller (LTDC) RM0090

490/1731 DocID018909 Rev 11

16.6 LTDC programming procedure

• Enable the LTDC clock in the RCC register

• Configure the required Pixel clock following the panel datasheet

• Configure the Synchronous timings: VSYNC, HSYNC, Vertical and Horizontal back

porch, active data area and the front porch timings following the panel datasheet as

described in the Section 16.4.1: LTDC Global configuration parameters

• Configure the synchronous signals and clock polarity in the LTDC_GCR register

• If needed, configure the background color in the LTDC_BCCR register

• Configure the needed interrupts in the LTDC_IER and LTDC_LIPCR register

• Configure the Layer1/2 parameters by programming:

– The Layer window horizontal and vertical position in the LTDC_LxWHPCR and

LTDC_WVPCR registers. The layer window must be in the active data area.

– The pixel input format in the LTDC_LxPFCR register

– The color frame buffer start address in the LTDC_LxCFBAR

– The line length and pitch of the color frame buffer in the LTDC_LxCFBLR

– The number of lines of the color frame buffer in the LTDC_LxCFBLNR

– if needed, load the CLUT with the RGB values and its address in the

LTDC_LxCLUTWR register

– If needed, configure the default color and the blending factors respectively in the

LTDC_LxDCCR and LTDC_LxBFCR registers

• Enable Layer1/2 and if needed the CLUT in the LTDC_LxCR register

• If needed, dithering and color keying can be enabled respectively in the LTDC_GCR

and LTDC_LxCKCR registers. It can be also enabled on the fly.

• Reload the shadow registers to active register through the LTDC_SRCR register.

• Enable the LCD-TFT controller in the LTDC_GCR register.

• All layer parameters can be modified on the fly except the CLUT. The new configuration

has to be either reloaded immediately or during vertical blanking period by configuring

the LTDC_SRCR register.

Note: All layer’s registers are shadowed. Once a register is written, it should not be modified again

before the reload has been done. Thus, a new write to the same register will override the

previous configuration if not yet reloaded.

Table 90. LTDC interrupt requests

Interrupt event Event flag Enable Control bit

Line LIF LIE

FIFO Underrun FUDERRIF FUDERRIE

Transfer Error TERRIF TERRIE
