DocID018909 Rev 11 1561/1731

RM0090 Flexible static memory controller (FSMC)

1588

3-2 MTYP[0:1] 0x1 or 0x2

1 MUXEN As needed

0 MBKEN 0x1

Table 238. FSMC_BTRx bit fields

Bit No. Bit name Value to set

31:30 Reserved 0x0

29:28 ACCMOD 0x0

27-24 DATLAT Data latency

23-20 CLKDIV

0x0 to get CLK = HCLK (not supported)

0x1 to get CLK = 2 × HCLK

19-16 BUSTURN Time between NEx high to NEx low (BUSTURN HCLK)

15-8 DATAST Don’t care

7-4 ADDHLD Don’t care

3-0 ADDSET[3:0] Don’t care

Table 237. FSMC_BCRx bit fields (continued)

Bit No. Bit name Value to set
