Serial audio interface (SAI) RM0090
956/1731 DocID018909 Rev 11
29.17.8 SAI xData register (SAI_xDR) where x is A or B
Address offset: block A: 0x020
Address offset: block B: 0x040
Reset value: 0x0000 0000
29.17.9 SAI register map
The following table summarizes the SAI registers.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
DATA[31:16]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
DATA[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:0 DATA[31:0]: Data
A write into this register has the effect of loading the FIFO if the FIFO is not full.
A read from this register has to effect of draining-up the FIFO if the FIFO is not empty.
Table 131. SAI register map and reset values
Offset
Register
and reset
value
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12
11
10
9 8 7 6 5 4 3 2 1 0
0x0004
or
0x0024
SAI_xCR1
Reserved
MCJDIV[3:0]
NODIV
Res.
DMAEN
SAIxEN
Reserved.
OutDri
MONO
SYNCE
N[1:0]
CKSTR
LSBFIRST
DS[2:0]
Res.
PRTCF
G[1:0]
MODE[
1:0]
Reset value 00000 00 000000010 0000
0x0008
or 0x0028
SAI_xCR2
Reserved
COMP[
1:0]
CPL
MUTECN[5:0]
MUTE VAL
MUTE
TRIS
FFLUS
FTH
Reset value 0000000000000000
0x000Cor
0x002C
SAI_xFRCR
Reserved
FSOFF FSPOL FSDEF
Reserved
FSALL[6:0] FRL[7:0]
Reset value 000 000000000000111
0x0010 or
0x0030
SAI_xSLOTR SLOTEN[15:0]
Reserved
NBSLOT[3:0]
SLOTS
Z[1:0}
Reserved
FBOFF[4:0]
Reset value0000000000000000 000000 00000
0x0014
or 0x0034
SAI_xIM
Reserved
LFSDET
AFSDETIE
CNRDYIE
FREQIE
WCKCFG
MUTEDET
OVRUDRIE
Reset value 0 000000
0x0018
or
0x0038
SAI_xSR
Reserved
FLVL[2:0]
Reserved
LFSDET
AFSDET
CNRDY
FREQ
WCKCFG
MUTEDET
OVRUDR
Reset value 000 0000100
