Random number generator (RNG) RM0090

762/1731 DocID018909 Rev 11

24.4.4 RNG register map

Table 115 gives the RNG register map and reset values.

Table 115. RNG register map and reset map

Offset

name

reset value

0x00

RNG_CR

0x0000000

Reserved

RNGEN

Reserved

0x04

RNG_SR

0x0000000

Reserved

SEIS

CEIS

Reserved

SECS

CECS

DRDY

0x08

RNG_DR

0x0000000

RNDATA[31:0]
