DMA controller (DMA) RM0090
338/1731 DocID018909 Rev 11
0x0030
DMA_S1PAR PA[31:0]
Reset value 00000000000000000000000000000000
0x0034
DMA_S1M0AR M0A[31:0]
Reset value 00000000000000000000000000000000
0x0038
DMA_S1M1AR M1A[31:0]
Reset value 00000000000000000000000000000000
0x003C
DMA_S1FCR
Reserved
FEIE
Reserved
FS[2:0]
DMDIS
FTH
[1:0]
Reset value 0 100001
0x0040
DMA_S2CR
Reserved
CHSEL
[2:0]
MBURST[1:0]
PBURST[1:0]
ACK
CT
DBM
PL[1:0]
PINCOS
MSIZE[1:0]
PSIZE[1:0]
MINC
PINC
CIRC
DIR
[1:0]
PFCTRL
TCIE HTIE
TEIE
DMEIE
EN
Reset value 0000000000000000000000000000
0x0044
DMA_S2NDTR
Reserved
NDT[15:.]
Reset value 0000000000000000
0x0048
DMA_S2PAR PA[31:0]
Reset value 00000000000000000000000000000000
0x004C
DMA_S2M0AR M0A[31:0]
Reset value 00000000000000000000000000000000
0x0050
DMA_S2M1AR M1A[31:0]
Reset value 00000000000000000000000000000000
0x0054
DMA_S2FCR
Reserved
FEIE
Reserved
FS[2:0]
DMDIS
FTH
[1:0]
Reset value 0 100001
0x0058
DMA_S3CR
Reserved
CHSEL[2:0]
MBURST[1:0]
PBURST[1:0]
ACK
CT
DBM
PL[1:0]
PINCOS
MSIZE[1:0]
PSIZE[1:0]
MINC
PINC
CIRC
DIR[1:0]
PFCTRL
TCIE HTIE
TEIE
DMEIE
EN
Reset value 0000000000000000000000000000
0x005C
DMA_S3NDTR
Reserved
NDT[15:.]
Reset value 0000000000000000
0x0060
DMA_S3PAR PA[31:0]
Reset value 00000000000000000000000000000000
0x0064
DMA_S3M0AR M0A[31:0]
Reset value 00000000000000000000000000000000
Table 51. DMA register map and reset values (continued)
Offset Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12
11
10
9 8 7 6 5 4 3 2 1 0
