Chrom-Art Accelerator™ controller (DMA2D) RM0090

372/1731 DocID018909 Rev 11

0x0040

DMA2D_OOR

Reserved

LO[13:0]

Reset value 00000000000000

0x0044

DMA2D_NLR

Res

PL[13:0] NL[15:0]

Reset value 000000000000000000000000000000

0x0048

DMA2D_LWR

Reserved

LW[15:0]

Reset value 0000000000000000

0x004C

DMA2D_AMTCR

Reserved

DT[7:0]

Reserved

Reset value 00000000 0

0x0050-

Ox03FF

Reserved

0x0400-

0x07FF

DMA2D_FGCLUT APLHA[7:0][255:0] RED[7:0][255:0] GREEN[7:0][255:0] BLUE[7:0][255:0]

Reset value XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX

0x0800-

0x0BFF

DMA2D_BGCLUT APLHA[7:0][255:0] RED[7:0][255:0] GREEN[7:0][255:0] BLUE[7:0][255:0]

Reset value XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX

Table 60. DMA2D register map and reset values (continued)
