DocID018909 Rev 11 65/1731
RM0090 Memory and bus architecture
112
0x5006 0800 - 0x5006 0BFF RNG
AHB2
Section 24.4.4: RNG register map on page 762
0x5006 0400 - 0x5006 07FF HASH Section 25.4.9: HASH register map on page 786
0x5006 0000 - 0x5006 03FF CRYP Section 23.6.13: CRYP register map on page 754
0x5005 0000 - 0x5005 03FF DCMI Section 15.8.12: DCMI register map on page 478
0x5000 0000 - 0x5003 FFFF USB OTG FS
Section 34.16.6: OTG_FS register map on
page 1315
0x4004 0000 - 0x4007 FFFF USB OTG HS
AHB1
Section 35.12.6: OTG_HS register map on
page 1458
0x4002 B000 - 0x4002 BBFF DMA2D Section 11.5: DMA2D registers on page 354
0x4002 8000 - 0x4002 93FF ETHERNET MAC
Section 33.8.5: Ethernet register maps on
page 1229
0x4002 6400 - 0x4002 67FF DMA2
Section 10.5.11: DMA register map on page 337
0x4002 6000 - 0x4002 63FF DMA1
0x4002 4000 - 0x4002 4FFF BKPSRAM
0x4002 3C00 - 0x4002 3FFF
Flash interface
register
Section 3.9: Flash interface registers
0x4002 3800 - 0x4002 3BFF RCC Section 7.3.25: RCC register map on page 267
0x4002 3000 - 0x4002 33FF CRC Section 4.4.4: CRC register map on page 115
0x4002 2800 - 0x4002 2BFF GPIOK
Section 8.4.11: GPIO register map on page 288
0x4002 2400 - 0x4002 27FF GPIOJ
0x4002 2000 - 0x4002 23FF GPIOI
Section 8.4.11: GPIO register map on page 288
0x4002 1C00 - 0x4002 1FFF GPIOH
0x4002 1800 - 0x4002 1BFF GPIOG
0x4002 1400 - 0x4002 17FF GPIOF
0x4002 1000 - 0x4002 13FF GPIOE
0x4002 0C00 - 0x4002 0FFF GPIOD
0x4002 0800 - 0x4002 0BFF GPIOC
0x4002 0400 - 0x4002 07FF GPIOB
0x4002 0000 - 0x4002 03FF GPIOA
0x4001 6800 - 0x4001 6BFF LCD-TFT
APB2
Section 16.7.26: LTDC register map on page 509
0x4001 5800 - 0x4001 5BFF SAI1 Section 29.17.9: SAI register map on page 956
0x4001 5400 - 0x4001 57FF SPI6
APB2 Section 28.5.10: SPI register map on page 918
0x4001 5000 - 0x4001 53FF SPI5
Table 1. STM32F4xx register boundary addresses (continued)
Boundary address Peripheral Bus Register map
