4.4.3.2 Setting the Order of DSP Processing Blocks
The following processing blocks (if available in the currently selected con-
figuration) can be placed individually at different locations along the Audio
Path of the channels:
  • EQ;
  • InsertPoint;
  • Dynamics(Compressor/Limiter/Expander/Gate/Sidechain);
  • Delay;
  • Fader&ON/OFF Mute.
The actual order of the system blocks is user-modifiable, and can be changed
at any time. The order is saved with snapshots and presets.
To change the system-block order, use the familiar drag-and-drop technique:
  • Clickontheselectedblocks,andholddownthetouchpadbutton;
  • Availablepositionsinthesignalpathareshownasareversed embossed
graphic;
  • Dragtheselectedblocktotherequiredpositioninthesignalpath;
  • Iftheblockcanbeinsertedatthatlocation,theblocknamewillturnred;
  • Releasethebuttonandtheselectedblockwillbeinsertedintothenew
location.
4.4.3.3 On-screen Toggles for Input Selector and Dynamics Key Selector
Input Selector To toggle the three-way input selector (In1, In2, Gen), click on the switch
icon that corresponds to the location at which you want the selector to point.
The Desk Input Selector keys will follow the changes, and display the correct
source.
Dynamics Key Selector To toggle the two-way input selector (Int, Ext), click on the switch icon that
corresponds to the location at which you want the selector to point.
The selector settings are saved within snapshots.
4.4.3.4 Editing the Channel User Labels
Double-click on the user label field (Usr) to open the Edit window. Proceed
to edit and/or change the Desk Label using the same techniques used in the
General Patch.
