Vista 1 Digital Mixing System
4-148 GC Operation
Document generated: 18.04.17
SW V5.3
Example for a .Pro-Bel File [TARGET_1 SOURCE_6]
Im23 Inp m 23 In1 left=D12L AES B 1 In4L left
Im24 Inp m 24 In1 left=D12L AES B 1 In4L left
[TARGET_1 SOURCE_7]
Im23 Inp m 23 In1 left=D11R AES B 1 In3R left
Im24 Inp m 24 In1 left=D11R AES B 1 In3R left
[TARGET_1 SOURCE_4]
Im23 Inp m 23 In1 left=
Im24 Inp m 24 In1 left=
[TARGET_0 SOURCE_0]
Im23 Inp m 23 In1 left=D11R AES B 1 In3R left
Im24 Inp m 24 In1 left=D11R AES B 1 In3R left
Im25 Inp m 25 In1 left=
Im26 Inp m 26 In1 left=
This file basically has a section for each used Source/Target combination.
The fixed labels are being used; ‘left’ is appended for left or mono sources/
targets, and ‘right’ is appended for right sources/targets.
Alternatively a short form of this file may be used in order to support the
standard case where all combinations of certain inputs and outputs should
be under control of an external device, there is a new file format introduced
allowing to only list the required inputs and outputs.
The alternate file format looks as follows:
[TARGETS]
1=i 1 B 1 Ch 1 left
[SOURCES]
1=I 1 B 1 Ch 1 left
This example defines Pro-Bel destination 1 to be ‘i 1’ output interface and
Pro-Bel source 1 to be ‘I 1’ output interface using the patch points fixed
label syntax.
The format is:
destination|source=fixed label of patch element + left
The appended ‘ left’ is kept on purpose in order to keep both formats
compatible.
Note: If a source or destination is listed twice by accident, once in the simple format
and once in an x/y combination, the simple format has priority, and the x/y
listing isn’t recognized. This situation is regarded as an error and should not
occur in regular cases.
4.7.17.1.1 Pro-Bel P-08 support
In case the user wants to extend the number of controlled patch points to above
1’000 it is recommended to use the Pro-Bel P-08 protocol. This protocol also
supports transferring labels from 3
rd
party router systems at the same time.
However, no control over internal patches such as patching from an input port
to an input channel is provided. Only one port can be used for P-08. Therefore
continue to use P-02 in case of multiple controllers present or if you want to
set system internal patches, e.g. channel input patches.
