5 D21M OPTION CARD AND STAGEBOX HANDLING
5.1 D21m Option Cards for Vista 1
Vista 1 provides a D21m extension slot at the rear. It is a dual D21m card slot,
where either one dual-slot or one or two single-slot cards can be inserted. Any
card of the D21m range available for Vista mixing systems can be used for
Vista 1.
Please note, that also the D23m Dual MADI card can be used in the option
slot of the Vista 1.
Name I/O Format
# of Console
Input Channels
# of Console
Output Channels
Connector Type Width (Slots) Order No.
Analog I/O Cards
Mic/Line Input (incl. Dir. Outs)
Mic/Line 4 (4 Dir. Outs) D25 f single A949.0427
Analog Insert
Line 4 4 D25 f single A949.0428
HD Mic/Line Input with Input
Transformers (incl. Dir. Outs)
Mic/Line 4 (4 Dir. Outs) D25 f single A949.0447
Analog Line In
Line 8 – D25 f single A949.0421
Analog Line Out
Line – 8 D25 f single A949.0420
Digital I/O Cards
AES I/O M2 (no SRCs)
AES/EBU 8 stereo (16 mono) 8 stereo (16 mono) 2 × D25 f double A949.0454
AES I/O M2 (Input SRCs)
AES/EBU 8 stereo (16 mono) 8 stereo (16 mono) 2 × D25 f double A949.0455
AES I/O M2 (In/Out SRCs)
AES/EBU 8 stereo (16 mono) 8 stereo (16 mono)
2 × D25 f;
ext. sync XLR
double A949.0456
MADI I/O */**
MADI
64 at 48 kHz (32 with
redundancy, 64 without
redundancy at 96 kHz)
64 at 48 kHz (32 with
redundancy, 64 without
redundancy at 96 kHz)
SC (optical)
SC (optical)
2 × RJ45
double
A949.0430
A949.0431
A949.0433
Dual MADI I/O (D23m) */**
MADI
128 at 48 kHz (64 with
redundancy, 128 without
redundancy at 96 kHz)
128 at 48 kHz (64 with
redundancy, 128 without
redundancy at 96 kHz)
4 × SFP double 5045304
ADAT I/O
ADAT 16 at 48 kHz (8 at 96 kHz) 16 at 48 kHz (8 at 96 kHz) TOSLINK (optical) single
A949.0425
A949.0429
TDIF I/O
TDIF 16 at 48 kHz (8 at 96 kHz) 16 at 48 kHz (8 at 96 kHz) 2 × D25 f double A949.0426
3G/HD/SD SDI Input
3G/SD/HD 8/16 – 2 × BNC single A949.0452
HD/SD SDI I/O
HD/SD 8 8 4 × BNC single A949.0442
3G/HD/SD SDI I/O
3G/HD/SD 16 16 4 × BNC single A949.0451
Dolby
®
E/Digital Decoder
AES/EBU
8
16
2 stereo (4 mono)
4 stereo (8 mono)
D15 f single
A949.0443
A949.0444
CobraNet
®
I/O
CobraNet 32 32 2 × RJ45 single A949.0445
Aviom A-Net
®
Output
A-Net – 16 RJ45 single A949.0446
EtherSound
®
I/O *
AoIP 64 64 3 × RJ45 double –
Rocknet
®
I/O
RockNet 64/48 (dep. on sw mode) 32/48 (dep. on sw mode) 3 × RJ45 , BNC, USB double –
BCD DTMF Dec./Glits Gen.
Internal 16 8 – single 5029584
BCD Blits/Glits Gen.
Internal – 8 – single 5029586
BCD Minimixer M2
Internal 32 32 – single 5029587
Livewire
®
I/O
AoIP 2 × 16 2 × 16 2 × RJ45 single 5014376
Dante
®
AoIP 64 64 2 × RJ45 , BNC double 5045044
BLU Link
®
BLU Link 32 32 2 × RJ45, D9 f single 5033340
Intercom BNC
AES/EBU 8 8 4 × BNC single 5037475
Intercom D-Type
AES/EBU 8 8 D25 f single 5037474
Non-Audio I/O Cards
GPIO w. Open-Collector Outp.
GPIO 16 16 2 × D25 f double A949.0435
GPIO w. Relay Outputs
GPIO 16 16 2 × D37 f double A949.0436
* The number of channels transmitted to and from a card may be defined in steps of 8 channels by using DIP switches on the card.
** Regardless of the number of channels defined with the DIP switches, a switch on the front panel switches the MADI protocol between the standard 56-chan-
nel format and the extended 64-channel format. Therefore this switch may have to be set to ‘56 channel’ protocol in order to operate correctly with third-party
MADI devices. In this case the number of channels set internally should not exceed 56.
