Studer Vista 1 - Dimensions

Vista 1 Digital Mixing System
Desk Operation 2-5
Document generated: 18.04.17
SW V5.3
2.1.3.1 Dimensions
Studer Vista 1 22/32-Fader-Versions, Dimensions
640 mm / 25.2”
740 mm / 29.1”
93 mm / 3.7”
565 mm / 22.3”
740 mm / 29.2”
93 mm
3.7”
281 mm / 11”
94 mm / 3.7”
3°
30°
45 mm
1.8”
104 mm
4.1”
1400 mm / 55.2” (32-Fader Version)
1490 mm / 58.7” (32-Fader Version)
1055 mm / 41.5” (22-Fader Version)
1145 mm / 45.1” (22-Fader Version)
