Studer Vista 1 - Page 340

Vista 1 Digital Mixing System
6-4 DSP Congurations
Document generated: 18.04.17
SW V5.3
Vista 1 STEREO Template The stereo configuration features a selection of channels necessary for a stereo
production. Groups and masters are in stereo, and also mix-minus (N–X)
busses are provided.
Path Type
Inputs
Mono
Inputs
Stereo
Inputs 5.1
Groups
Mono
Groups
Stereo
Groups 5.1
Masters
Mono
Masters
Stereo
Masters 5.1
AUX Mono
AUX Stereo
Control
Groups
Downmix
N–X Bus
Multitrack
Bus
Qty 80 12 - - 8 - - 4 - 8 4 10 - 8 -
Processing
Blocks
ALL ALL - - ALL - - DYN - GEQ - - - - -
Vista 1 Surround Template The surround configuration features a good mix of channels necessary for a
surround production. Groups and masters are in 5.1 surround format, also mix
minus busses are provided. Four automatic surround-to-stereo and to-mono
downmixers are also available in this DSP structure. Two mono groups are
provided for commentary mixing in surround productions.
Path Type
Inputs
Mono
Inputs
Stereo
Inputs 5.1
Groups
Mono
Groups
Stereo
Groups 5.1
Masters
Mono
Masters
Stereo
Masters 5.1
AUX Mono
AUX Stereo
Control
Groups
Downmix
N–X Bus
Multitrack
Bus
Qty 32 8 6 2 - 4 - - 2 6 4 10 6 6 -
Processing
Blocks
ALL ALL ALL ALL - ALL - - DYN
PAR.
EQ
None - - - -
Vista 1 FOH / Monitor Templates There are two session configurations provided for public address (PA) appli-
cations, for which the console is either used at the FOH position to provide
sound for a large audience, or near the stage to provide monitoring mixes for
the performing artists. A large number of AUX busses is provided, all of them
equipped with graphic equalizers (GEQ).
FOH:
Path Type
Inputs
Mono
Inputs
Stereo
Inputs 5.1
Groups
Mono
Groups
Stereo
Groups 5.1
Masters
Mono
Masters
Stereo
Masters 5.1
AUX Mono
AUX Stereo
Control
Groups
Downmix
N–X Bus
Multitrack
Bus
Qty 150 10 - - - - 4 6 - 10 - 32 - - -
Processing
Blocks
EQ
DEL
INS
EQ
DEL
INS
- - - - ALL ALL -
GEQ
DEL
- - - - -
Monitor:
Path Type
Inputs
Mono
Inputs
Stereo
Inputs 5.1
Groups
Mono
Groups
Stereo
Groups 5.1
Masters
Mono
Masters
Stereo
Masters 5.1
AUX Mono
AUX Stereo
Control
Groups
Downmix
N–X Bus
Multitrack
Bus
Qty 85 10 - - - - 10 - - 15 15 30 - - -
Processing
Blocks
ALL ALL - - - - INS - - GEQ GEQ - - - -
